No. of Ports 1
Pass Through Data Rates 10/100/1000 Mbps
Power over Ethernet Pin Assignment and Polarity:
Output 4/5 (+), 7/8 (–)
Output Power Voltage: 48Vdc
User Port Power: 15.4W (Guaranteed)
Input Power AC Input Voltage: 90 to 264 Vac
Requirements AC Input Current: 0.5A @110-240Vac
AC Frequency: 47 to 63 Hz
Dimensions 53 mm (W) x 32.5 mm (H) x 140 mm (L)
2.09 in. x 1.28 in. x 5.5 in
Weight .44 lbs (200g)
Indicator User Indicator:
Channel Power (Green)
Connectors Shielded RJ-45, EIA 568A and 568B
Environmental Operating Ambient Temperature:
Conditions 32o to 104oF (0 to 40oC)
Operating Humidity:
Maximum 90%, Non-condensing
Storage Temperature:
–4o to 158oF (–20o to 70oC)
Storage Humidity:
Maximum 95%, Non-condensing
Operating Altitude:
–1000 to 10,000 ft. (–304.8 to 3048 m)
Reliability MTBF: 100,000 hrs. @25oC
Thermal Rating 13 BTU/Hr (@240VAC)
Warranty 1-year
Regulatory IEEE 802.3af (PoE), RoHS Compliant,
WEEE Compliant, CE
Electromagnetic FCC Part 15, Class B
Emission & Immunity EN 55022 Class B
EN 55024, VCCI
Safety Approvals UL/cUL Per EN 60950-1
GS Mark Per IEC 60950-1
